Developer Documentation

Delivered In Time API

A simple JSON over HTTPS API for pulling LTL freight rates, booking shipments, tracking them and retrieving paperwork — connected to whatever system you already run.

Connect anything

A WMS or ERP, order management, a spreadsheet, or an automation tool like Zapier or Make.

Four endpoints

Rates, booking, shipment status and documents. No SDK required.

Scoped to you

Credentials only ever reach your own shipments. No invoices, payments or account access.

Getting Started

1Sign in to your Delivered In Time customer portal and open API Access.
2Click Generate Credentials. Your API username and password appear once — copy the password immediately and store it in your system.
3Wait for approval. An administrator reviews the request; the status on that page turns Active when the credentials are live.
4Call Get Rates, then Book Shipment with the returned quoteReference. Poll Shipment Status and pull Documents as needed.

Base URL

https://osto-freight-47397175.base44.app/functions

Authentication

Every request uses HTTP Basic authentication with your API username and password. Send it on each call — there is no token exchange or session to manage.

Authorization header

Authorization: Basic base64(API_USERNAME:API_PASSWORD)

# Most HTTP clients build this for you:
curl -u "YOUR_API_USERNAME:YOUR_API_PASSWORD" ...

Requests must be HTTPS. Treat the password like any other secret — store it in your system's credential store, never in client-side code. If it leaks, generate a new pair from the portal; the old one stops working immediately.

Errors & Limits

Successful responses always include success: true. Failures return the matching HTTP status with a machine-readable code and a human message.

Error response

{
  "success": false,
  "error": {
    "code": "validation_failed",
    "message": "One or more fields are missing or invalid",
    "fields": [
      { "field": "origin.zip", "message": "origin.zip must be a 5-digit ZIP" }
    ]
  }
}

Status	Code	Meaning
400	validation_failed	A field is missing or invalid. The response lists each offending field.
401	unauthorized	Missing, malformed, or incorrect Basic auth credentials.
403	not_approved	The credentials exist but have not been approved yet, or were revoked.
404	shipment_not_found	No shipment with that number exists on your account.
404	quote_not_found	The quoteReference is unknown or belongs to another account.
429	rate_limited	Too many requests. Slow down and retry after a short pause.
502	booking_failed	The carrier rejected the booking. The message carries the carrier's reason.

Requests are rate limited per credential. Quoting is the heaviest call — cache rates you have already retrieved rather than re-quoting the same lane repeatedly. Every call is logged and visible to our support team.

POST/functions/apiGetRates

Get Rates

Returns live rates from every carrier available on the lane, already priced for your account. The response includes a quoteReference you pass to Book Shipment — rates are only bookable through that reference.

Parameters

Field	Type	Required	Description
pickupDate	string	Required	Requested pickup date, YYYY-MM-DD.
origin.city	string	Required	Origin city.
origin.state	string	Required	Origin state, 2-letter code.
origin.zip	string	Required	Origin 5-digit ZIP.
origin.locationType	string	Optional	Business (default), Residential, or a limited-access type.
destination.*	object	Required	Same shape as origin: city, state, zip, locationType.
handlingUnits	array	Required	One entry per pallet/unit type. At least one required.
handlingUnits[].quantity	number	Optional	Number of identical units. Defaults to 1.
handlingUnits[].weight	number	Required	Weight in pounds, per unit.
handlingUnits[].length	number	Required	Length in inches.
handlingUnits[].width	number	Required	Width in inches.
handlingUnits[].height	number	Required	Height in inches.
handlingUnits[].description	string	Required	Commodity description.
handlingUnits[].freightClass	string	Optional	NMFC freight class, e.g. "70". Calculated by density when omitted.
handlingUnits[].nmfc	string	Optional	NMFC item code.
handlingUnits[].stackable	boolean	Optional	Whether the units can be stacked.
accessorials	array	Optional	Accessorial codes — see the code list below.

Request

curl -X POST https://osto-freight-47397175.base44.app/functions/apiGetRates \
  -u "YOUR_API_USERNAME:YOUR_API_PASSWORD" \
  -H "Content-Type: application/json" \
  -d '{
    "pickupDate": "2026-10-02",
    "origin":      { "city": "Newark", "state": "NJ", "zip": "07102" },
    "destination": { "city": "Atlanta", "state": "GA", "zip": "30303",
                     "locationType": "Business" },
    "handlingUnits": [{
      "quantity": 2, "weight": 850,
      "length": 48, "width": 40, "height": 50,
      "description": "Packaged retail goods",
      "freightClass": "70", "stackable": false
    }],
    "accessorials": ["LGDL"]
  }'

Response 200

{
  "success": true,
  "quoteReference": "DITQ-1001",
  "pickupDate": "2026-10-02",
  "rates": [
    {
      "carrier": "SAIA",
      "carrierName": "Saia LTL Freight",
      "total": 412.87,
      "currency": "USD",
      "transitDays": 3,
      "estimatedDeliveryDate": "2026-10-07",
      "quoteNumber": "DITQ-1001"
    },
    {
      "carrier": "ABF",
      "carrierName": "ABF Freight",
      "total": 468.20,
      "currency": "USD",
      "transitDays": 2,
      "estimatedDeliveryDate": "2026-10-06",
      "quoteNumber": "DITQ-1001"
    }
  ]
}

Rates are sorted cheapest first. total is your all-in price in USD — no additional markup is applied at booking.
quoteReference is the DITQ number for the entire quote and all carrier rates. Carrier-internal quote references are never exposed; pass the DITQ number and selected carrier to book.
A quoteReference stays bookable as long as the carrier honors the rate; re-quote if the pickup date moves.
Carriers that fail to return a rate are silently omitted rather than failing the whole request.

POST/functions/apiBookShipment

Book Shipment

Books one of the carriers returned by Get Rates. The lane, freight and pickup date come from the quoteReference — you supply the street-level shipper and consignee details, pickup and delivery windows, and any references. The response carries the BOL, PRO and pickup number.

Parameters

Field	Type	Required	Description
quoteReference	string	Required	The quoteReference from Get Rates.
carrier	string	Required	Carrier code from the rates array, e.g. "SAIA".
shipper.name	string	Required	Pickup company name.
shipper.address1	string	Required	Pickup street address.
shipper.address2	string	Optional	Suite, unit, dock.
shipper.contact	string	Required	Pickup contact name.
shipper.phone	string	Required	Pickup contact phone, 10 digits.
shipper.email	string	Optional	Pickup contact email.
consignee.*	object	Required	Same shape as shipper, for the delivery location.
pickup.readyTime	string	Required	Pickup window opens, HH:MM 24-hour.
pickup.closeTime	string	Required	Pickup window closes, HH:MM 24-hour.
pickup.instructions	string	Optional	Notes printed in the BOL pickup remarks.
delivery.readyTime	string	Required	Delivery window opens, HH:MM 24-hour.
delivery.closeTime	string	Required	Delivery window closes, HH:MM 24-hour.
delivery.instructions	string	Optional	Notes printed in the BOL delivery remarks.
poNumber	string	Optional	Your PO number, printed on the BOL.
shipmentId	string	Optional	Your internal shipment/order ID.
referenceNumbers	array	Optional	Additional reference strings printed on the BOL.
specialInstructions	string	Optional	General instructions printed on the BOL.

Request

curl -X POST https://osto-freight-47397175.base44.app/functions/apiBookShipment \
  -u "YOUR_API_USERNAME:YOUR_API_PASSWORD" \
  -H "Content-Type: application/json" \
  -d '{
    "quoteReference": "DITQ-1001",
    "carrier": "SAIA",
    "shipper": {
      "name": "Acme Distribution", "address1": "120 Dock St",
      "contact": "Dana Reyes", "phone": "9735550142",
      "email": "dock@acme.com"
    },
    "consignee": {
      "name": "Southeast Retail DC", "address1": "900 Peachtree Ind Blvd",
      "contact": "Marcus Hall", "phone": "4045550188"
    },
    "pickup":   { "readyTime": "09:00", "closeTime": "16:00",
                  "instructions": "Use dock 4" },
    "delivery": { "readyTime": "08:00", "closeTime": "15:00" },
    "poNumber": "PO-88231",
    "shipmentId": "WMS-40192",
    "referenceNumbers": ["WAVE-7781"]
  }'

Response 200

{
  "success": true,
  "alreadyBooked": false,
  "quoteNumber": "DITQ-1001",
  "bolNumber": "OSTOF214",
  "proNumber": "77137243070",
  "pickupNumber": "4412098",
  "pickupDate": "2026-10-02",
  "carrier": "SAIA",
  "total": 412.87,
  "currency": "USD",
  "shipmentId": "68f3c2b14b2e7d0012ab3499",
  "pickupWarning": null
}

Booking is idempotent per quoteReference — repeating the call returns the original shipment with alreadyBooked: true instead of double-booking.
proNumber and pickupNumber depend on the carrier; some assign them after dispatch, in which case they arrive later via Shipment Status.
pickupWarning is non-null when the shipment booked but the pickup request needs manual follow-up — the shipment is still valid.
shipmentId is the Delivered In Time record ID; store it alongside bolNumber for your own reconciliation.

GET/functions/apiGetShipment

Shipment Status

Returns the current numbers, status and dates for one of your shipments. Poll this to keep your own system in sync — hourly is plenty for LTL.

Parameters

Field	Type	Required	Description
bolNumber	string	Optional	The BOL number returned at booking. Either this or proNumber is required.
proNumber	string	Optional	The carrier PRO number. Either this or bolNumber is required.

Request

curl "https://osto-freight-47397175.base44.app/functions/apiGetShipment?bolNumber=OSTOF214" \
  -u "YOUR_API_USERNAME:YOUR_API_PASSWORD"

Response 200

{
  "success": true,
  "shipment": {
    "quoteNumber": "DITQ-1001",
    "bolNumber": "OSTOF214",
    "proNumber": "77137243070",
    "pickupNumber": "4412098",
    "carrier": "SAIA",
    "status": "in_transit",
    "trackingStatus": "in_transit",
    "voided": false,
    "pickupDate": "2026-10-02",
    "estimatedDeliveryDate": "2026-10-07",
    "deliveryDate": null,
    "total": 412.87,
    "referenceNumbers": ["PO: PO-88231", "WAVE-7781"],
    "documents": [
      { "type": "BOL", "name": "BOL_OSTOF214.pdf" },
      { "type": "Pallet Labels", "name": "Labels_OSTOF214.pdf" }
    ],
    "bookedAt": "2026-09-23T14:22:08.114Z"
  }
}

status values: created, onboard, picked_up, in_transit, at_destination, out_for_delivery, delivered, cancelled.
Parameters can be sent as a query string (GET) or a JSON body (POST) — both are accepted.
documents lists what is available; call the Documents endpoint to get download links.

GET/functions/apiGetDocuments

Documents

Returns time-limited download links for a shipment's paperwork — the Bill of Lading and pallet labels, plus delivery documents such as the POD once the carrier releases them. Anything not yet generated is created on demand.

Parameters

Field	Type	Required	Description
bolNumber	string	Optional	The BOL number. Either this or proNumber is required.
proNumber	string	Optional	The carrier PRO number. Either this or bolNumber is required.

Request

curl "https://osto-freight-47397175.base44.app/functions/apiGetDocuments?bolNumber=OSTOF214" \
  -u "YOUR_API_USERNAME:YOUR_API_PASSWORD"

Response 200

{
  "success": true,
  "bolNumber": "OSTOF214",
  "proNumber": "77137243070",
  "documents": [
    {
      "type": "BOL",
      "name": "BOL_OSTOF214.pdf",
      "url": "https://...signed-url...",
      "expiresAt": "2026-09-23T15:22:08.114Z"
    },
    {
      "type": "Pallet Labels",
      "name": "Labels_OSTOF214.pdf",
      "url": "https://...signed-url...",
      "expiresAt": "2026-09-23T15:22:08.114Z"
    }
  ]
}

Links expire one hour after the call — download the file, don't store the URL.
Every document is a PDF. Fetch the url with a plain GET; no auth header is needed on the signed link.
The first call for a shipment may take a few extra seconds while the BOL and labels are generated.

Accessorial Codes

Pass these codes in the accessorials array on Get Rates. They are priced into the returned rate and carried through to the booking and BOL.

LGPULiftgate at Pickup

LGDLLiftgate at Delivery

INSPUInside Pickup

INSDLInside Delivery

APTPUAppointment Pickup

APTDLAppointment Delivery

NOTPUNotification Before Pickup

NOTDLNotification Before Delivery

SORTPUSort & Segregate at Pickup

SORTDLSort & Segregate at Delivery

LIMACCLimited Access

Residential and limited-access locations are set throughlocationTypeon the origin or destination rather than an accessorial code.
